SPECIFICATION :
Frame
Genius Carbon / IMP / HMX /
BB92 / Carbon swingarm with 180PM
U-Mono Link / Tapered Headtube
IDS SL DM dropouts for 142x12mm
BB height adj.
Travel
Front 150mm
Rear 150 - 100 - Lockout / Shock 200X57
Fork
FOX 34 Float Factory Air / Kashima
FIT4 3-Modes with low speed adj. / 15x100mm QR axle
Tapered steerer / Reb. Adj. / Lockout
Rear Shock
FOX NUDE SCOTT custom w. travel / geo adj.
3 modes: Lockout - Traction Control -Descend
DPS / EVOL / Kashima / Reb. Adj.
Remote System
SCOTT TwinLoc Remote Technology
3 modes front and rear / integ. Grip clamp
Headset
Syncros FL2.0 Press Fit / Tapered 1.5" - 1 1/8"
OD 50/61mm / ID 44/55mm
Rear Derailleur
Shimano XTR RD-M9000 SGS
DM / Shadow Plus / 22 Speed
Front Derailleur
Shimano XTR FD-M9025-E / DM
Shifters
Shimano XTR SL-M9000-I / Rapidfire Plus
2 way release / Ispec 2 clamp
Brakes
Shimano XTR M9020 Disc
Pads w/Fin / 180mm F & R /SM-RT99 CL Icetech Rotor
Crankset
Shimano XTR FC-M9020-2 / Hollowtech 2
36x26 T
BB-Set
Shimano SM-BB94-41A / shell 41x89.5mm
Handlebar
Syncros FL1.0 Carbon mini Riser
12mm rise / 9° / 760mm / Syncros Pro lock-on grips
Handlebar Stem
Syncros TR1.0 Carbon
7050 Carbon wrapped / oversize 31.8mm
1 1/8" / +6° angle
Seatpost
FOX Transfer Dropper Remote
31.6mm / S size 100mm / M, L & XL 150mm
Seat
Syncros XM1.0 / Carbon rails
Hub (Front)
Syncros TR1.5 CL / 15x100mm
Made by DT Swiss
Hub (Rear)
Syncros TR1.5 CL / 142x12mm
RWS axle/ 36T Rachet System
Made by DT Swiss
Chain
Shimano CN-M901-11
Cassette
Shimano XTR CS-M9000 / 11-40 T
Spokes
DT Swiss Aero Comp
Rims
Syncros TR1.5 / 28H
Tubeless ready
Tires
Schwalbe Nobby Nic EVO / 2.35
67EPI Kevlar Bead / Tubeless Easy
PaceStar compound
Weights
11.80kg / 26.01lbs
